FLP-WP WELL GLASS FITTING UPTO 45 W LED (FLAT GLASS

PRODUCT : CAT.NO. – WG/1240

ENCLOSURE : FLAME PROOF (Ex –d ), Ga s G r o u p I I A , I I B , I I C

As per IS/IEC 60079-1 : 2014

PROTECTION : WEATHER PROOF IP – 66 AS PE R I S / I E C 6 0 5 2 9 : 2 0 0 1

(Reaffirmed 2014)

AREA & TEMP.CLASS : Ex db IIC T6 Gb ( EX tb / tc IIIC T85 C Db/Dc

( ZONE 1 & 2 & Zone 21 & 22 )

CERTIFICATION : CIMFR , BIS, PESO

TEMPERATURE CLASS : T 6

MATERIAL : DIE CAST ALUMINIUM ALLOY

FINISH : EPOXY POWDER COATED SHADE AS PER IS : 5

EARTHING : 1 No INTERNAL & 2 No’s EXTERNAL

HARDWARE : STAINLESS STEEL

GASKET : 'O' RING ENDLESS GA S K E T N E O P R E N E / S I L I C O N

NAME PLATE : SS NAME PLATE CUM WARNING PLATE

GLASS : HEAT RESISTANT CLEAR TYPE-A TOUGHENED

ENTRIES : 2 Nos M20 / ½ “ NPT / EQUIVALENT

VOLTAGE : 140 V – 270 V ( 240 V AC )

POWER FACTOR : ≥ 0.95

INPUT FREQUENCY : 50 Hz.

EFFICACY : ≥100 LUMEN PER WATT

COLOUR ( CCT) : 3000K / 5700K / 6500 K / O R A S S P E C I F I E D

CRI : ≥ 80 RA

THD : ≤ 10 % THD

SURFACE TEMP. : MAX . 70 ̊

SURGE PROTECTION : 10 KV SPD

LED MAKE : CITIZEN / OSRAM / BTR I DGELUX / EQUIVALEN

DRIVER MAKE : OSRAM / PHILIPS / FULHAM / EQUIVALENT
